ST STM32G474E-EVAL User Manual page 56

STM32G474E-EVAL I/O assignment
Pin name
PC2 24
PC3 25
PF2 26
PA0 27
PA1 28
PA2 29
VSS_2 30
VDD_2 31
PA3 32
PA4 33
PA5 34
PA6 35
PA7 36
PC4 37
PC5 38
PB0 39
PB1 40
PB2 41
VSSA 42
VREF- [42]
VREF+ 43
VREF+ 44
VDDA 45
VSS_3 46
VDD_3 47
PF11 48
PF12 49
PF13 50
PF14 51
56/66
Table 41. STM32G474E-EVAL I/O assignment (continued)
Double motor control
STM32G474E-EVAL
MC1_Ain+_ADC12_IN8
MC1_Bin+_ADC12_IN9
-
MC1_Encoder_A_TIM2_CH1
MC1_OPAMP1_VINP
MC1_OPAMP1_VOUT
-
-
MC1_OPAMP1_VINM/
1_VINP
MC_DAC1_OUT1
MC_DAC1_OUT2
MC1|MC2_OPAMP2_VOUT
MC1_OPAMP2_VINP
MC1_heatsink_temp_ADC2_IN5
MC1|MC2_OPAMP2_VINM
MC2_OPAMP3_VINP
MC2_OPAMP3_VOUT
MC2_OPAMP3_VINM
-
-
-
-
-
-
-
-
-
-
-
UM2514 Rev 5
General-purpose features
STM32G474E-EVAL
QSPI_BK2_IO1
QSPI_BK2_IO2
FMC_A2
DIFF_ADC12_IN1 || MFX_IRQ_OUT
DIFF_ADC12_IN2
QSPI_BK1_NCS
-
-
QSPI_CLK
DAC
USBPD_FRSTX
QSPI_BK1_IO3
QSPI_BK1_IO2
QSPI_BK2_IO3
USBPD_Isense_ADC2_IN11
QSPI_BK1_IO1
QSPI_BK1_IO0
USBPD_Discharge
-
-
-
-
-
-
-
LED3
FMC_A6
FMC_A7
FMC_A8
UM2514
