What is a Smart-Vue
wireless end-point
module?
6 Smart-Vue CO and Temperature Module Installation Guide
2
Smart-Vue wireless end-point modules connect to remote devices (e.g.,
sensors) to monitor their status, transmitting information wirelessly to a
central database managed by Thermo Scientific Smart-Vue Server software.
Alerts can be sent automatically in case these readings indicate specific alarm
conditions configured in the software.
LCD display with CO
temperature, signal and
battery indicators
Push-button
Cable to connect to
CO2/temperature
module's ribbon cable
Figure 2. Smart-Vue wireless end-point module with cable for CO
end-point module
Cable to connect
to Smart-Vue
module cable
Figure 3. Smart-Vue CO

What is a Smart-Vue wireless end-point module?

,
2
Plug for DC
adapter
CO2 Sensor
intake
sensor
2
2
CO Sensor intake
2
Cable to connect to
Smart-Vue module
