  • Page 1 Thermo Scientific Orion VERSA STAR™ RDO/DO/Temperature Module Reference Guide...
  • Page 2 Ross and the COIL trade dress are trademarks of Thermo Fisher Scientific, Inc. and its subsidiaries. AQUAfast, AQUASensors, BOD AutoEZ, ionplus, KNIpHE, LogR, No Cal, ORION, perpHect, PerpHecT, pHISA, pHuture, Pure Water, Sage, ROSS, ROSS Ultra, Sure-Flow, Titrator PLUS, and TURBO2 are registered trademarks of Thermo Fisher Scientific, Inc.
  • Page 3: Table Of Contents

    Thermo Scientific Orion VERSA STAR™ RDO/DO/Temperature Module Table of Contents Chapter 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Chapter 2 Module Overview .
  • Page 4 This page intentionally left blank.
  • Page 5: Introduction

    Chapter 1 Introduction Thank you for your purchase of the Thermo Scientific Orion VERSA STAR™ RDO/DO/Temperature Module. This module is for use with the Thermo Scientific Orion VERSA STAR Advanced Electrochemistry Benchtop Meter. Some key features of this module include: • Works with and automatically recognizes Orion polarographic DO and RDO optical/...
  • Page 6 This page intentionally left blank.
  • Page 7: Module Overview

    Orion VERSA STAR Reference Guide. The Reference Guide is on the CD included with the meter and also available at www.thermoscientific.com/water. Module Connections and Inputs 1. Select either the RDO or Polarographic DO probe based on sample range and testing requirements. 2. Place selected probe in the meter’s electrode arm. If using the RDO probe, attach the included adapter. 3. Attach the 9 pin mini-DIN connection into the RDO/DO module. 4. Attach the stirrer to the side of the meter and into the meter's electrode arm, if needed for your test method. 5. Set up area with deionized rinse water, sample and other supplies. 6. Connect the meter for data collection (Hyperterminal, LIMS, Star Printer, etc), if desired. 7. Power the Orion VERSA STAR meter, stirrer, and data collection device(s). RDO/DO Module 9 pin mini-DIN connector for RDO or polarographic DO probe Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 8: Module Maintenance

    (changes to red color at 30 days) Calibration information The information on the display can be customized. Enter the setup menu to make changes. 1. Press Setup. 2. Use the arrow keys to highlight Inst. Settings, press (f3/select) key. 3. Use the arrow key to highlight Display View. Press (f3/select) key. 4. Follow the onscreen prompts to choose what you would like to see on the measurement screen. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 9: Setup Menus

    Read Type AutoRead, Timed, Continuous Measurement Unit mg/L, % Pressure Compensation Auto, Manual Salinity Correction Auto*, Manual Limit, CalDue, Set Point Alarm** * For automatic salinity correction of RDO/DO reading, ensure oxygen probe and conductivity cell are in the same sample. ** Limit and set point alarm default set to ‘off’. Cal due alarm set to 12 hours. 3. Press the f1 (Back) button to step back to the main screen. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 10: Read Type Information

    • Continuous – The meter will continuously measure and update the display. This read type is useful when performing an experiment that requires continuous measurements to be taken. Press the log/print/0 key to export the measurement to the data log, if the data log is enabled in the setup menu, and to a printer or computer, if a printer or computer is connected to the meter and enabled in the setup. RDO Probe Information The RDO probe works with a unique optical cap. Information exclusive to this cap, such as: • Serial number • Remaining cap life • Date of manufacture can be found in the setup menu when the RDO probe is connected and recognized as the measurement mode. Verify RDO probe is connected. 2. Press setup/3. 3. Use the arrows to highlight the channel with RDO if needed. Press f3 (Select) key. 4. Use the right arrow to highlight RDO Electrode Info to review information. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 11: Setup Menu For Temperature

    Setup Menu for Temperature All of the temperature measurement settings are found in Temperature Setup menu for each measurement. Temperature Unit ºC or ºF selection Temperature Input and Type Ch-1 ATC, Ch-2 ATC, Ch-3 ATC, Ch-4 ATC, MTC Ch-1* ATC only or All ATC allows all ATCs to be Temperature Cal calibrated at once * This number will change to match the setup menu channel. Temperature probes can be set up in the measurement mode of the sample you are measuring. Ch-1 ATC allows the temperature probe to be used in more than one channel for temperature-compensated measurements, such as when a pH electrode and a 2-cell conductivity cell are in the same measurement sample. Temperature is a critical pH and conductivity measurement as the measurement values require a temperature correction to determine the reference value, often 25 ºC in the America and 20 ºC in Europe. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 12 This page intentionally left blank. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 13: Rdo/Do Calibration

    • Set Zero – A zero point calibration requires oxygen-free solution. This method needs to be repeated each time the probe is replaced or modified (cap change with RDO probes; membrane change or fresh electrolyte with polarographic DO probes). This calibration is generally not required unless measurements will be taken below 10% saturation or 1 mg/L. An air or water calibration needs to be performed prior to a zero point calibration. Calibration Procedure 1. Press cal/. to enter calibration mode. 2. Follow the screen prompts for calibration. 3. The calibration can be saved or printed when complete. 4. Information for the last calibration can be displayed on the main measurement screen. Refer to this reference guide, Chapter 2 Module Overview, Display Information section for more information. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 14 This page intentionally left blank. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 15: Temperature Calibration

    DO probes have varying temperature accuracies, usually ±0.5°C to ±2°C. Use this function only if necessary. Since the temperature offset calculated during the calibration is applied to all future temperature measurements, recalibrate if a different probe is used. For temperature calibration, the probe needs to be connected to the meter and the calibration solution should have a known, stable temperature. It is recommended that two NIST-traceable thermometers be used to measure and verify solution temperature. 1. Press f3 (setup) key. 2. Use the arrow keys to highlight the channel that the temperature probe is connected to. Press f3 (select). 3. Use the arrow keys to highlight Temperature and press f3 (select). 4. Use the arrow keys to highlight the appropriate Temperature Cal option and press f3 (select). 5. Follow the onscreen prompts. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 16 This page intentionally left blank. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 17: Measurement

    Chapter 6 Measurement After successful calibration, the samples can be tested. 1. Rinse the RDO or DO probe with deionized water, blot dry with lint-free tissue. 2. Place RDO/DO probe, conductivity cell if required, and optional stirrer in first sample. 3. If the meter is in AutoRead mode (meter default) press measure (esc) (1) key. If the meter is in continuous or timed read mode, the meter will immediately start taking readings. 4. If in AutoRead mode and datalog is enabled (default), the reading will automatically be stored when the “AR” appears. If in continuous read mode and datalog is enabled, press log/print (0) key to store into the meter’s memory. Note: To enable or disable datalogging, press setup and select Inst. Settings. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 18 This page intentionally left blank. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 19: Methods

    The meter stores up to ten methods per channel with the last calibration data stored for each method. Use the channel setup to access and modify methods. 1. Press f3 (setup) key. 2. Use the arrow keys to highlight the appropriate channel. Press f3 (select). 3. Use the arrow keys to highlight Method and press f3 (select). 4. The methods can be loaded, copied, saved and edited by following the onscreen prompts. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 20 This page intentionally left blank. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 21: Data Storage And Review

    For more information on these settings, refer to the Orion VERSA STAR Reference Guide, Chapter 3 Instrument Settings to turn on Data Log to enable data storage. Datalog Review This option allows for stored data to be: • reviewed • printed individually, in a group or all • deleted • analyzed with general statistical information The datalog will reflect a screen capture of all the information at the time of datalogging. To review datalog information • Press log view (9) key • Press f3 (select) key • Follow prompts to review information Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 22: Calibration Review

    The information will match the information recorded for that calibration. To review calibration information 1. Press log view (9) key. 2. Press right arrow (6) key to select CalLog information and down arrow (8) to highlight the desired parameter. 3. Press f3 (select) key and follow the prompts. Example Calibration Log Display Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 23: Customer Services

    Recommended Actions Measurement is outside the allowable measurement range. Check electrode Measurement is connection and settings in the setup menu. Clean the electrode according to the flashing 9999 and over electrode user guide and recalibrate the electrode with new buffers or standards. range or under range. If the error continues, perform the meter self test in the diagnostics menu. The measurement The meter is in AutoRead mode. (AR icon appears solid on the display.) Press freezes and will measure (esc)/1 key to take a new reading or go to setup to change the read type. not change. Assistance After troubleshooting all components of your measurement system, contact Technical Support. Within the United States call 1.800.225.1480 and outside the United States call 978.232.6000 or fax 978.232.6031. In Europe, the Middle East and Africa, contact your local authorized dealer. For the most current contact information, or the latest application and technical resources for Thermo Scientific Orion products, visit www.thermoscientific.com/water. Warranty and Registration To register your new meter and for the most current warranty information, visit www.thermoscientific.com/water. WEEE Compliance This product is required to comply with the European Union’s Waste Electrical & Electronic Equipment (WEEE) Directive 2002/96/EC. It is marked with the symbol above. Thermo Fisher Scientific has contracted with one or more recycling/disposal companies in each EU Member State and this product should be disposed of or recycled through them. Further information on compliance with these directives, the recyclers in your country, and information on Thermo Scientific Orion products that may assist the detection of substances subject to the RoHS Directive are available at www.thermoscientific.com. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 24: Declaration Of Conformity

    Orion Star A-series meters are EMC Class A Conforms with the following directives and standards: EN61326-1:2006 Electromagnetic Compatibility (EMC Directive) Electrical equipment for measurement, control and laboratory use - EMC requirements EN61010-1:2001 Safety Standards UL61010-1:2004 Safety requirements for electrical equipment for measurement, CAN/CSA C22 .2 No . 61010-1-04 control and laboratory use - general requirements Cheow Kwang Chan Place and Date of Issue: QA/Regulatory Manager 12 December, 2011 Singapore Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 25: Rdo/Do/Temperature Module Specifications

    450.0 to 850.0 mm Hg Pressure Correction Salinity Factor Correction Automatic when used with conductivity module and probe or manual; 0 to 45 ppt Calibration Water saturated air, air saturated water, Features manual (Winkler) and zero point Probe Type Polarographic or RDO Temperature Range 0 to 50 °C, 32 to 122 ºF Resolution Relative Accuracy ±0.1 Offset Calibration 1 point Input 9-pin mini-DIN NOTE: We reserve the right to make improvements. Specifications subject to change without notice. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 26: Ordering Information

    - Orion VERSA STAR meter - Orion VERSA STAR dissolved oxygen/temperature module - Electrode arm with redesigned holder - Universal power adapter VSTAR32 Orion VERSA STAR RDO/Dissolved Oxygen Benchtop Meter Kit - Orion VERSA STAR meter - Orion VERSA STAR dissolved oxygen/temperature module - 083005MD Orion polarographic DO probe - 080017 calibration sleeve for DO probe - 080513 DO probe maintenance kit - 970802 BOD funnel/stirrer - 080360 BOD adapter - Electrode arm with redesigned holder - Universal power adapter Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 27 - Orion VERSA STAR conductivity/temperature module - Electrode arm with redesigned holder - Universal power adapter VSTAR52 Orion VERSA STAR pH/Conductivity Benchtop Meter Kit - Orion VERSA STAR meter with pH/temperature module - Orion VERSA STAR conductivity/temperature module - 8157BNUMD Orion ROSS Ultra Triode pH/ATC probe - 013005MD Orion DuraProbe conductivity cell, K=0.475 - 810199 ROSS solution kit (475 mL each of pH 4, 7 and 10 buffers; storage solution; cleaning solution; and pH electrode storage bottle) - 011007 conductivity standard, 1413 µS, 5x60 mL - Electrode arm with redesigned holder - Universal power adapter Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 28 - Universal power adapter VSTAR91 Orion VERSA STAR pH/ISE/Conductivity/RDO/Dissolved Oxygen Benchtop Multiparameter Meter Set - Orion VERSA STAR meter - Two Orion VERSA STAR pH/ISE/temperature modules - Orion VERSA STAR conductivity/temperature module - Orion VERSA STAR dissolved oxygen/temperature module - Two 096019 Orion Star stirrer probes - Two electrode arms with redesigned holders - Universal power adapter Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 29 Ultimate Benchtop Multiparameter Meter Set - Orion VERSA STAR meter - Orion VERSA STAR pH/ISE/temperature module - Orion VERSA STAR conductivity/temperature module - Orion VERSA STAR dissolved oxygen/temperature module - 8157BNUMD Orion ROSS Ultra Triode pH/ATC probe - 013005MD Orion DuraProbe conductivity cell, K=0.475 - 083005MD Orion polarographic DO probe - Two 096019 Orion Star stirrer probes - 080017 calibration sleeve for DO probe - 080513 DO probe maintenance kit - 970802 BOD funnel/stirrer - 080360 BOD adapter - 810199 ROSS solution kit (475 mL each of pH 4, 7 and 10 buffers; storage solution; cleaning solution; and pH electrode storage bottle) - 011007 conductivity standard, 1413 µS, 5x60 mL - Two electrode arms with redesigned holders - Universal power adapter Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 30 Orion conductivity calibration resistor kit 9512HPBNWP Orion high-performance ammonia ISE 9512BNWP Orion standard ammonia ISE 951007 Ammonia standard, 1000 ppm, 475 mL 951210 Low-level ammonia ISA 951211 Ammonia ISA, 475 mL 951209 Fill solution for Orion high-performance ammonia ISE, 60 mL 951202 Fill solution for standard ammonia ISE , 60 mL 951213 Ammonia ISE storage solution 9609BNWP Orion fluoride combination ISE 040906 Fluoride standard, 1 ppm with TISAB II, 475 mL 040907 Fluoride standard, 2 ppm with TISAB II, 475 mL 040908 Fluoride standard, 10 ppm with TISAB II, 475 mL 940909 TISAB II, 1 gallon 8611BNWP Orion ROSS sodium combination ISE Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 31: Advanced Features

    Manual salinity correction can be used for dissolved oxygen readings reported as mg/L on all Orion VERSA STAR Meter with RDO/DO/Temperature module systems. The manual salinity correction factor must be entered as ppt (parts per thousand). Conductivity Salinity Conductivity Salinity Conductivity Salinity at 20 °C Correction at 20 °C Correction at 20 °C Correction (mS/cm) Value (ppt) (mS/cm) Value (ppt) (mS/cm) Value (ppt) This table was calculated from the International Oceanographic Tables, Vol. 1, National Institute of Oceanography of Great Britain, Womley, Godaming, Surrey, England and Unesco, Paris 1971. Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 32 Notes Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module...
  • Page 33 This page intentionally left blank.
  • Page 34 Water Analysis Instruments North America 9 0 0 1 : 2 0 0 8 166 Cummings Center Beverly, MA 01915 USA Toll Free: 1-800-225-1480 Tel: 1-978-232-6000 info.water@thermo.com Netherlands Tel: (31) 033-2463887 info.water.uk@thermo.com India Tel: (91) 22-4157-8800 wai.asia@thermofisher.com Japan Tel: (81) 045-453-9175 wai.asia@thermofisher.com China Tel: (86) 21-68654588...
