5.2

Recommended Operating Conditions

Table 39 indicates the recommended operating conditions for Mars AX3 FPGA module. The values given
are for reference only; for details please refer to the Artix-7 Datasheet [19].
Symbol Description
VCC_MOD Supply voltage relative to GND
VCC_3V3 3.3 V supply voltage relative to GND
VCC_BAT Supply voltage for the RTC and encryption key storage
VCC_IO_[x]
Output drivers supply voltage relative to GND
VCC_CFG_[x]
V_IO I/O input voltage relative to GND
V_ADC Analog I/O input voltage for the ADC
Temperature range for commercial modules (C)
Temperature
Temperature range for industrial modules (I)
Table 39: Recommended Operating Conditions
Warning!
*
The components used on the hardware are specified for the relevant temperature range. The user
must provide adequate cooling in order to keep the temperature of the components within the specified
range.
D-0000-426-004
*
*
43 / 47
Rating
3.0 to 5.5
3.15 to 3.45
2.0 to 3.45
Refer to Section 2.9.5
-0.2 to V +0.2
CCO
0 to 1.5
0 to +70
-40 to +85
Version 06, 16.02.2021
Unit
V
V
V
V
V
V
C
C
