1 Overview

1.1

General

1.1.1

Introduction

The Mars AX3 FPGA module combines the Xilinx Artix-7® All Programmable FPGA device with fast DDR3
SDRAM, quad SPI flash, Gigabit Ethernet, high-speed LVDS I/O, and is available in industrial temperature
range, forming a complete and powerful embedded processing system. It is ideal for high-speed commu-
nication and DSP applications, offering high-performance and low cost.
The SO-DIMM form factor allows space-saving hardware designs and quick and simple integration of the
module into the target application.
The use of the Mars AX3 FPGA module, in contrast to building a custom FPGA hardware, significantly re-
duces development effort and redesign risk and improves time-to-market for the embedded system.
Together with Mars base boards, the Mars AX3 FPGA module allows the user to quickly build a system
prototype and start with application development.
1.1.2

Warranty

Please refer to the General Business Conditions, available on the Enclustra website [1].
Warning!
Please note that the warranty of an Enclustra module is voided if the FPGA fuses are blown. This
operation is done at own risk, as it is irreversible. Enclustra cannot test the module in case of a warranty
product return.
1.1.3

RoHS

The Mars AX3 FPGA module is designed and produced according to the Restriction of Hazardous Substances
(RoHS) Directive (2011/65/EC).
1.1.4

Disposal and WEEE

The Mars AX3 FPGA module must be properly disposed of at the end of its life.
The Waste Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC) is not applicable for the Mars
AX3 FPGA module.
1.1.5

Safety Recommendations and Warnings

Mars modules are not designed to be "ready for operation" for the end-user. These can only be used in
combination with suitable base boards. Proper configuration of the hardware before usage is required.
Ensure that the power supply is disconnected from the board before inserting or removing the Mars AX3
FPGA module, connecting interfaces, or connecting jumpers.
Touching the capacitors of the DC-DC converters can lead to voltage peaks and permanent damage; over-
voltage on power or signal lines can also cause permanent damage to the module.
