1.4.5
Mars PM3 Base Board
Mars 200-pin SO-DIMM socket
FMC LPC (Low Pin Count) connector (72 I/Os)
40-pin GPIO connector (optional, shared with FMC I/Os)
RJ45 Gigabit Ethernet connector
Mini HDMI connector for PCIe and LVDS applications (module dependent)
Cypress FX3 USB 3.0 device controller (16-bit Slave-FIFO interface or 32-bit Slave-FIFO interface shared
with FMC I/Os)
USB 3.0 B device connector
USB 2.0 A host connector
Micro USB 2.0 B device connector with FTDI USB device controller
Battery holder for the real-time clock
microSD card holder
Fan connector, various switches and LEDs
Single 12 V DC supply voltage or USB bus-powered (with restrictions)
Form factor: 100
Please note that the available features depend on the equipped Mars module type.
1.5

Xilinx Tool Support

The FPGA devices equipped on the Mars AX3 FPGA module are supported by the Vivado HL WebPACK
Edition software, which is available free of charge. Please contact Xilinx for further information.
D-0000-426-004
72 mm (pico-ITX)
8 / 47
Version 06, 16.02.2021
