1 Overview

1.1

General

1.1.1

Introduction

The Andromeda XZU90 module combines the Xilinx Zynq® UltraScale+ MPSoC (Multiprocessor System-
on-Chip) device with fast DDR4 ECC SDRAM, eMMC flash, dual parallel quad SPI flash, dual Gigabit Eth-
ernet PHY, USB 3.0 and thus forms a complete and powerful embedded processing system. This module
is suitable for high-speed applications due to the high number of transceivers and due to the superior
module connector performance.
The use of the Andromeda XZU90 module, in contrast to building a custom MPSoC hardware, significantly
reduces development effort and redesign risk and improves time-to-market for the embedded system.
1.1.2

Warranty

Refer to the General Business Conditions, available on the Enclustra website [1].
Tip
The warranty of Enclustra modules is void if the FPGA's one-time programmable eFuses are blown. This
operation is irreversible. Enclustra cannot test the module in case of a product return.
NOTICE
Data loss or unusable product
The fuses of the FPGA can be blown to activate the user-defined Advanced En-
cryption Standard (AES). After blowing the fuses, only content encrypted using a
specific key can be loaded on the FPGA. Your key is unique and cannot be retrieved
in case of loss.
1.1.3

RoHS

The Andromeda XZU90 module is designed and produced according to the Restriction of Hazardous
Substances (RoHS) Directive (2011/65/EC).
1.1.4

Disposal and WEEE

The Andromeda XZU90 module must be properly disposed of at the end of its life.
The Waste Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC) is not applicable for the
Andromeda XZU90 module.
1.1.5

Safety Recommendations and Warnings

Andromeda modules are not designed to be "ready for operation" for the end-user. These can only be
used in combination with suitable base boards. Proper configuration of the hardware before usage is
required.
Ensure that the power supply is disconnected from the board before inserting or removing the An-
dromeda XZU90 module, connecting interfaces, or connecting jumpers.
D-0000-458-001
Keep your key in a secure location.
