IDE Primary Master / Slave:
IDE Secondary Master / Slave:
The options for these items are found in its sub menu. By pressing the
<ENTER> key, you are prompt to enter the sub menu of the detailed options
as shown below:
CMOS Setup Utility – Copyright (C) 1984-2001 Award Software
IDE HDD Auto-Detection
IDE Primary Master
Access Mode
Capacity
Cylinder
Head
Precomp
Landing Zone
Sector
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
Table 1 – IDE Primary Master sub menu
Descriptions on each item above are as follows:
1. IDE HDD Auto-detection
Press the enter key to auto-detect the HDD on this channel. If detection
is successful, it fills the remaining fields on this menu.
2. IDE Primary Master
There are three available options on this category, namely: None, Auto,
and Manual. By selecting "Manual", you can set the remaining fields
on this screen, such as -
a. Cylinder – Set the number of cylinders for this hard disk.
b. Head – Set the number of read/write heads.
c. Precomp - ***Warning! Setting a value of 65535 means no HDD.
d. Landing Zone
e. Sector – Set the number of sector per track
'
