Chapter 5 Award BIOS Setup

5-6. INTEGRATED PERIPHERALS

Choose INTEGRATED PERIPHERALS from the main setup menu, a
display will be shown on screen as below:
CMOS Setup Utility – Copyright (C) 1984-2001 Award Software
On-Chip IDE Channel0
On-Chip IDE Channel1
IDE Prefetch Mode
Primary Master PIO
Primary Slave PIO
Secondary Master PIO
Secondary Slave PIO
Primary Master UDMA
Primary Slave UDMA
Secondary Master UDMA
Secondary Slave UDMA
Init Display First
IDE HDD Block Mode
Onboard FDC Controller
Onboard Serial Port 1
Onboard Serial Port 2
UART 2 Mode
IR Function Duplex
TX,RX inverting enable
Onboard Parallel Port
Onboard Parallel Mode
X ECP Mode Use DMA
X Parallel Port EPP Type
Onboard Serial Port 3
X Serial Port 3 Use IRQ
Onboard Serial Port 4
X Serial Port 4 Use IRQ
Onboard Legacy Audio
Sound Blaster
SB I/O Base Address
SB IRQ Select
SB DMA Select
MPU-401
MPU-401 I/O Address
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
Page: 5-16
Integrated Peripherals
[Enabled]
[Enabled]
[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[PCI Slot]
[Enabled]
[Enabled]
[3F8/IRQ4]
[2F8/IRQ3]
[Standard]
[Half]
[No, Yes]
[378/IRQ7]
[Normal]
3
EPP1.9
[3E8H]
IRQ10
[2E8H]
IRQ11
[Enabled]
[Disabled]
[220H]
[IRQ 5]
[DMA 1]
[Disabled]
[330-333H]
F6:Fail-Safe Defaults
Integrated Peripherals Setup Screen
