Chapter 1 Introduction
MOUSE CONNECTOR :
PS/2 mouse connector with min DIN cable.
BUS SUPPORT :
Internal PCI Bus for LAN, Sound, & IDE.
Internal AGP Bus for VGA.
External PCI Bus.
DISPLAY :
Built-in VIA VT8604, support CRT & LCD (PanelLink).
Integrated S3®'s Savage4™ 2D/3D/Video Accelerator.
Optimized Shared Memory Architecture (SMA).
2~32 MB Frame Buffer using system memory.
Support simultaneous display of CRT & LCD.
Interface:
One 16-pin connector, support for CRT Monitor.
One 20-pin connector, support for DFP (PanelLink).
One 21-pin connector, support up to 18bit LVDS, with selectable
resolution for 1024 x 768 (default), 800 x 600, and 640 x 480. (More more
details on Appendix C).
WATCHDOG :
I / O port 0443H to Enable watchdog.
I / O port 0441H to Disable watchdog.
Selectable for Reset / NMI Watchdog function.
Time-out timing select 0 / 8 / 16 / 24 / 32 / 40 / 48 / 56 / 64 / 72 / 80 / 88 /
96 / 104 / 112 / 120 sec +/- 25%.
IDE INTERFACE :
Two IDE ports, support Ultra DMA-100/66/33.
Two channel, support up to four devices.
FLOPPY DISK DRIVER INTERFACE :
Support up to two Floppy Disk Drives, 3.5" and 5.25" (360K / 720K /
1.2M / 1.44M / 2.88M / LS-120).
DISK-ON-CHIPS SOCKET :
A 32-pin SSD socket on board, supports up to 144MB Disk-on-chips.
