Figure 2 SmartOTDR: Front view
Indicators
Hard keys
Figure 3 SmartOTDR: Side and top views
VFL USB host Optical test port (OTDR, light
source and optional Power
Meter)
User Manual
Chapter 2 Introducing the SmartOTDR
7SMART102 Rev006
Unpacking the SmartOTDR
5'' Color
Capacitive
Touchscreen
Buzzer
Mini USB AC/DC
port Input
7
