Deleting a directory / file

1 Select the directory or file(s) to be deleted (see
on page
2 Press Edit > Delete.
A confirmation dialog box displays.
3 Press Yes to delete the selected directory or file(s).
Press No to cancel the deletion.
Working with directories and files from the
explorer

Creating a directory

To create a new directory from the explorer page:
1 Check the cursor is set on the left of the screen
2 Select the storage media into which the directory must be created
3 If you want to create a sub-directory, select the directory into which it must be
created.
4 Press the right menu key Create Directory.
The edition keypad displays
5 Enter a name for this directory
6 Press Enter key to validate the new directory

Opening files

Once a file is selected, press Load menu key.
Opening several files at the same time can be done exclusively with
trace files (example: all OTDR trace files if a reference trace has been
defined). Other type of files (PDF, TXT...) must be open one by one.
If different types of files have been selected in the Explorer, only the
last one selected will open.
84).
User Manual

Working with directories and files from the explorer

"Directories and Files selections"
7SMART102 Rev006
Chapter 8 File management
87
