Chapter 11 Maintenance and Troubleshooting
Troubleshooting
Figure 88 Setting a new battery
3 Close the battery door
The instrument can be turned on.
NOTE
Take care to set the connector of the battery in the right way on the plug of
the base!
Do not forget the black foam to wedge the battery.
When putting a battery back into its seating, make sure that its con-
nector engages correctly in the socket and that the door is correctly
closed.
Contact VIAVI local Sales Service to get a new battery.
Do not use any battery other than the one supplied with the instru-
ment, or supplied by VIAVI.
