• No
• Session Mode
• Permanent Mode
• Permanent with password
The password to access VNC can be modified:
1 Touch the Change password menu key.
2 Enter the current password in the Edition keypad and touch Enter to validate.
3 Enter the new password and touch Enter to validate.
Ethernet > Mode
Parameters of the local Ethernet network to which the SmartOTDR is connected:
• Config 1 to 4
– Site Name
– IP Address
– IP Mask
– IP Gateway
1
– DNS
– Domain name
• Dynamic
1.Domain Name Server
the screen cannot be remote on to a PC or on to another
SmartOTDR.
the Remote screen function is inactive once the
SmartOTDR is switched off.
the Remote screen function is still active when the
SmartOTDR is switched off and restarted.
Same function as the Permanent mode, with an access
to the equipment via VNC protected by a password:
42000
static mode enabling input of the configuration of 4 sites. If this
parameter is selected, the following parameters must be
entered:
the user can enter the name of the site in the Edit menu.
IP address of the SmartOTDR
address of the mask of the sub-network
IP address of the machine enabling access outside the sub-
network.
IP address of the machine providing the IP address on the basis
of the name
name of the local network to which the SmartOTDR is
connected.
in this mode, which requires a DHCP server, the SmartOTDR
requests an IP address from this server which will be allocated
dynamically if dynamic host configuration is activated on the
local network.
After selecting this mode or after power-on, the SmartOTDR
tries to establish a connection to obtain an address from a
DHCP server. If for any reason, this process fails, the
