1. UNPACKING
1)

Product Model

Check that the delivered product is what you have ordered.
2)

Product Configuration

This product consists of the items specified in the table below. Check that all items
are delivered when unpacking for the first time.
Product Description
1
Actuator unit
2
Driver unit
3
Resolver cable
4
Actuator cable
5
Instruction manual
6
Accessories
Plug
Hood
Fuse
Mounting kit
Note 1: If the option is selected, the cable will be either a standard cable (-D
cable (-DM
[H]
Type of the cable and length can not be changed after system delivery due to
required adjustment at the time of assembling process.
[GH]
Type of the cable (standard or moving) and length (2 to 20m) can be changed by
purchasing individual cables.
Note 2: In case of the optional driver for 100VAC, two fuses are attached.
CAUTION:
Discontinue
Table 1.1 Product Configuration
Standard cable 4m (Note 1)
Standard cable 4m (Note 1)
MR-50M (HONDA TSUSHIN KOGYO CO., LTD.)
MR-50L (HONDA TSUSHIN KOGYO CO., LTD.)
Standard model: FGBO (10A, 250V) (FUJI TERMINAL)
Models complying with EU directives: 19195 (10A, 250VAC)
(WICKMAN)
), whose length is 2 to 30m long (H) or 2 to 20m long (GH).
The standard cable is not for applications where
repetitive bending actions are added. For such
applications, use the optional moving cable.
Do not add an excessive tension to cables and
connectors.
— 1-1 —

UNPACKING

Quantity
1
1
1
1
1
1
1
3 (Note2)
2
) or a moving
[SMB-14E]
