2. INSTALLATION

2.1 Environment

• Use the product within the following ambient temperature ranges:
RCS2 (standard type)
RCS2-T2 (low hydraulic type)
RCS2-G4 (heat-resistant type)
• For compressed air, use clean and dry air that has been passed through an air filter.
Use an air filter in the circuit and be careful with the filtration rate (a filter that removes particles exceeding
5 μm is desirable), flow rate, and mounting position (install the filter near the directional control valve).

2.2 Unpacking

• Check that the model number ordered and the model number indicated on the product are the same.
• Check the exterior of the product for any damage.
• When storing the product, attach a sealing plug to the piping port to prevent foreign matters from entering
the cylinder. Remove the sealing plug before piping.
Compressed air
−10°C to 60°C (no freezing)
5°C to 50°C
5°C to 120°C
Air filter
Clean
compressed air
8
