INTRODUCTION
Thank you for choosing our ABSODEX.
ABSODEX is a direct drive indexing unit developed to drive intermittently operated turntables or
the like of general industrial assembling machines and testing machines flexibly and accurately.
This instruction manual is exclusively for ABSODEX AX Series H type driver and GH type driver.
It is inapplicable to other types.
Use a dialog terminal for programming and other purposes. The dialog terminal is common for
the H and GH type drivers.
Before starting operation of our product, read through operation precautions and maintenance
and inspection items described below to keep the initial performance and operate without
failures.
COMPATIBILITY
1) Compatible type [GH]
With the "GH type," compatibility among the actuator and driver sets is provided.
Therefore it can be used in combination with actuators, drivers or cables marked with
different serial numbers.
Description for only the "compatible" type is marked with [GH] in this instruction manual.
2) Incompatible type [H]
With the "H type," compatibility among the actuator and driver sets is not provided.
Therefore use the actuator, driver and cable of the same serial number in combination.
If an actuator and a driver having different serial numbers are used or the length or type of
the cable is changed, the performance described in specifications is not satisfied. Be
careful.
Description for only the "incompatible type" is marked with [H] in this instruction manual.
3) No mark is given to the description common for the "compatible" and "incompatible" types in
this instruction manual.
CAUTION:
Discontinue
The same cable
"compatible" and "incompatible" types.
If the "compatible type" is connected with the
"incompatible type," breakage may be caused.
— 1 —

INTRODUCTION COMPATIBILITY

connector is used for the
[SMB-14E]
