Removal and Installation Procedures

Removal and Installation Procedures

Preparation

Adjustment After Repair
List of Modules
4–6
This section contains procedures for removal and installation of all mechanical
and electrical modules.
WARNING.
Before performing this or any other procedure in this manual, read the
General Safety Summary and Service Safety Summary found at the beginning of
this manual.
To prevent damage to the instrument components, read Preventing ESD in this
section.
Before doing any procedure in this section, disconnect the power cord from the
line voltage source.
This section contains the following items:
This preparatory information that you need to properly do the following
procedures.
List of tools required to remove and disassemble all modules.
Procedures for removal and reinstallation of the modules.
NOTE. Read Required Equipment for a list of the tools needed to remove and
install modules in this instrument. (See page 4-8, Required Equipment.) Read the
cleaning procedure before disassembling the instrument for cleaning.
After the removal and replacement of a module due to electrical failure, perform
the adjustment procedures. Refer to the Adjustment Procedures section.
The Replaceable Parts section provides a list of all replaceable modules.
AWG5000B and AWG5000C Series Service Manual
