Tektronix AWG5000B Series Service Manual page 146

Replaceable parts list – AWG1G/CLK1G/OUT1G modules
Fig. & Tektronix
index part
number number
5-16-
-1 337-4400-00
337-4400-00
-2 211-1050-00
211-1050-00
-3 343-1716-00
343-1716-00
-4 343-0549-00
343-0549-00
-5
671-6158-00
671-6158-00
-6 211-1050-00
211-1050-00
-7 211-1050-00
-8 174-5303-00
-9 211-1050-00
AWG5000B and AWG5000C Series Service Manual
Serial no.
Model effective
AWG50x2C
AWG50x2B
AWG50x4C
AWG50x4B
AWG50x2C
AWG50x2B
AWG50x4C
AWG50x4B
AWG50x2C
AWG50x2B
AWG50x4C
AWG50x4B
AWG50x2C
AWG50x2B
AWG50x4C
AWG50x4B
AWG50x2C
AWG50x2B
AWG50x4C
AWG50x4B
AWG50x2C
AWG50x2B
AWG50x4C
AWG50x4B
Serial no.
discont'd Qty Name & description
AWG1G/CLK1G/OUT1G MODULES
1 BRACKET, BNC CABLES
2 BRACKET, BNC CABLES
2 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
4 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
3 CLAMP, CABLE; WIRE ROUTING, FOR 3MM OD,4 WAY,
0.870(W) X 0.370(D) X 0.260(H), NYLON66, UL94V-0,
W/ADHESIVE, SAFETY CONTROLLED,PB-FREE
6
CLAMP, CABLE; WIRE ROUTING, FOR 3MM OD,4 WAY,
0.870(W) X 0.370(D) X 0.260(H),NYLON66,UL94V-0,
W/ADHESIVE ,SAFETY CONTROLLED,PB-FREE
3 STRAP,TIEDOWN; 0.098 W X 4.0 L,ZYTEL
6 STRAP,TIEDOWN; 0.098 W X 4.0 L,ZYTEL
1 CIRCUIT BOARD ASSY; OUT1G,OUTPUT 1.2GS
2 CIRCUIT BOARD ASSY; OUT1G,OUTPUT 1.2GS
8 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
16 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
12
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
1
CABLE ASSY ELEC: 2X4, 9.5IN L,18 AWG X 8, 39-01-2085,
MOLEX
12 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
Replaceable Parts
5–29
