Table 4-10: Hardware error (cont.)
Error code Error log message
300000209 The download (AwgController) timeout period
has expired.
300000210
The system cannot find the file specified.
(PLD121B.Bit)
300000211 An attempt was made to load a program with an
incorrect format. (PLD121B.Bit)
300000212 The download (MemoryController-INIT) timeout
period has expired.
300000213 The download (MemoryController-INIT) timeout
period has expired.
300000214 The download (MemoryController-DONE)
timeout period has expired.
300000215 The download (MemoryController) timeout
period has expired.
300000216 The system cannot find the file specified.
(PLD120B.Bit)
300000217 An attempt was made to load a program with an
incorrect format. (PLD120B.Bit)
300000218 The DCM timeout period has expired.
300000219 The LOCKED timeout period has expired.
300000220 A PLD121B.bit is old version.
300000221 A PLD120B.bit is old version.
310000000 The parameter is incorrect.
390000001 The calibration data is invalid. The default value
is used.
390000002 The instrument started with Manufacturing
mode.
390000003
The calibration data is invalid. The default value
is used.

After Repair

AWG5000B and AWG5000C Series Service Manual
After you replace a module, follow the instructions about adjustment and
performance verification. This is essential to ensure proper instrument
performance. (See page 3-1, Adjustment After Repair.)
Possible defect
on board Note
MIO, AWG1G MIO: U300, AWG1G: U1000,
MIO-AWG1G cable
N/A Software/disk drive
N/A Software/disk drive
MIO, AWG1G MIO: U300, AWG1G: U1000, U4000x
Product configuration (number of
channels) is wrong.
MIO, AWG1G MIO: U300, AWG1G: U1000, U4000x
Product configuration (number of
channels) is wrong.
MIO, AWG1G MIO: U300, AWG1G: U1000, U4000x
Product configuration (number of
channels) is wrong.
MIO, AWG1G MIO: U300, AWG1G: U1000, U4000x
Product configuration (number of
channels) is wrong.
N/A Software/disk drive
N/A Software/disk drive
MIO MIO: U300
MIO MIO: U300
N/A Software/disk drive
N/A Software/disk drive
N/A Software/disk drive
N/A This is not a defect.
N/A This is not a defect.
N/A This is not a defect.
