Troubleshooting
Table 4-8: Diagnostics error (cont.)
Error code Error log message
CH 2 waveform memory
122000000 HwDiagWaveformMemory channel2, testNo
Data bus [IC-Pin] Error expected data=xxxxxxxx
actual data=xxxxxxxx testNo: 1'st 2'nd IC: IC
number Pin: Pin number
122000001
HwDiagWaveformMemory channel2, Address
Bus=xxxxxxxx [IC-Pin] Error expected
data=xxxxxxxx actual data=xxxxxxxx IC: IC
number Pin: Pin number
122000002 HwDiagWaveformMemory channel2, Memory
Cell testNo BIT[CNT] Error testNo: 1'st or 2'nd
BIT: Data bus bit CNT: data bit
CH 3 waveform memory
123000000 HwDiagWaveformMemory channel3, testNo
Data bus [IC-Pin] Error expected data=xxxxxxxx
actual data=xxxxxxxx testNo: 1'st 2'nd IC: IC
number Pin: Pin number
123000001 HwDiagWaveformMemory channel3, Address
Bus=xxxxxxxx [IC-Pin] Error expected
data=xxxxxxxx actual data=xxxxxxxx IC: IC
number Pin: Pin number
123000002 HwDiagWaveformMemory channel3, Memory
Cell testNo BIT[CNT] Error testNo: 1'st or 2'nd
BIT: Data bus bit CNT: data bit
CH 4 waveform memory
124000000 HwDiagWaveformMemory channel4, testNo
Data bus [IC-Pin] Error expected data=xxxxxxxx
actual data=xxxxxxxx testNo: 1'st 2'nd IC: IC
number Pin: Pin number
124000001 HwDiagWaveformMemory channel4, Address
Bus=xxxxxxxx [IC-Pin] Error expected
data=xxxxxxxx actual data=xxxxxxxx IC: IC
number Pin: Pin number
124000002 HwDiagWaveformMemory channel4, Memory
Cell testNo BIT[CNT] Error testNo: 1'st or 2'nd
BIT: Data bus bit CNT: data bit
Data timing margin
125000000 HwDiagDataTiming channel=1, Value is out of a
range max=xx min=xx
125000001 HwDiagDataTiming channel=2, Value is out of a
range max=xx min=xx
125000002
HwDiagDataTiming channel=3, Value is out of a
range max=xx min=xx
4–62
Possible defect
on board Note
AWG1G AWG1G: U4000B, U4500B, U4510B,
U4520B, U4530B, U4600B, U4610B,
U4620B, U4630B.
AWG1G AWG1G: U4000B, U4500B, U4510B,
U4520B, U4530B, U4600B, U4610B,
U4620B, U4630B.
AWG1G AWG1G: U4000B, U4500B, U4510B,
U4520B, U4530B, U4600B, U4610B,
U4620B, U4630B.
AWG1G AWG1G: U4000C, U4500C, U4510C,
U4520C, U4530C, U4600C, U4610C,
U4620C, U4630C.
AWG1G AWG1G: U4000C, U4500C, U4510C,
U4520C, U4530C, U4600C, U4610C,
U4620C, U4630C.
AWG1G AWG1G: U4000C, U4500C, U4510C,
U4520C, U4530C, U4600C, U4610C,
U4620C, U4630C.
AWG1G AWG1G: U4000D, U4500D, U4510D,
U4520D, U4530D, U4600D, U4610D,
U4620D, U4630D.
AWG1G AWG1G: U4000D, U4500D, U4510D,
U4520D, U4530D, U4600D, U4610D,
U4620D, U4630D.
AWG1G AWG1G: U4000D, U4500D, U4510D,
U4520D, U4530D, U4600D, U4610D,
U4620D, U4630D.
AWG1G, CLK1G AWG1G: U1000 CLK1G: U3200
AWG1G, CLK1G AWG1G: U1000 CLK1G: U3200
AWG1G, CLK1G AWG1G: U1000 CLK1G: U3200
