Replaceable Parts
Replaceable parts list – AWG5000C Series front-panel assembly
Fig. & index Tektronix
number part number
5-5-
-1 259-0193-00
-2 407-5537-00
-3 211-1236-00
-4 650-5362-00
-5 407-5536-00
-6 878-0257-00
-7 211-1050-00
-8 211-1050-00
-9 174-5256-00
-10 679-6492-00
-11 174-5254-00
-12 174-5161-00
-13 129-1631-00
-14 679-6063-01
-15 260-2819-00
-16 407-5176-00
-17 174-5160-00
-18 211-1050-00
-19 174-5807-00
-20 211-1050-00
5–8
Serial no. Serial no.
effective dis-cont'd Qty Name & description
FRONT-PANEL ASSEMBLY
1 FLEX CIRCUIT; ON/STAND BY SWITCH
1 BRACKET; TOUCH SCREEN
4 SCREW, MACHINE; W/HEAVY PATCH THREADLOCKING MATERIAL;
4-40 X 0.25, PNH, 410 SS PASSIVATEDT, T10
1 TOUCH SCREEN ASSEMBLY
1
BRACKET; DISPLAY, FRONT PANEL, SAFETY CONTROLLED
1 CIRCUIT BOARD ASSY; FSW, FRONT PANEL SWITCH
2 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
7 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
1 CABLE ASSY ELEC: 7P,0.1,1.18IN L,AWG 24,UL1061, 87456-5,
103958-4, TYCO,3-640441-3,AMP,FOR PWR SW & LEDS
1 CIRCUIT BD ASSY: LEDA , LED ADAPTER
1
CABLE ASSY ELEC: 2X5P,0.1,19.7 IN L,AWG 24,W/KEYING PLUG,
87456-5, 87809-1 CONTACT,AMP
1 CABLE ASSY;DISPLAY ADAPTER TO PCI BOARD
2 LOCKING STANDOFF; NATURAL 3/8 IN. SPACER,NYLON 66,1M/BAG
TOP/BOTTOM HOLES: 156 IN. /.187 IN. TOP/BOTTOM PANEL THK:
.062 IN
1 CIRCUIT BOARD ASSY;FRONTPANEL
1 SWITCH,KEYPAD; FRONT PANEL
1 BRACKET;TRIM,FRONTPANEL,SHEET METAL,SAFETY CONTROLLED
1 CABLE ASSY;DISPLAY ADAPTER TO DISPLAY; SAFETY CONTROLLED
2 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
1 CABLE, ASSEMBLY (DISPLAY BACKLIGHT)
4 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
