4. Disconnect the cables at J1050, J1060, J2000, and J5000 from the AWG1G
board.
5. Disconnect these Peltola cables:
The cable at J6020A from the AWG1G board to the CH1 & CH2 OUT1G
board (J1000).
The cable at J6030A from the AWG1G board to the CH1 & CH2 OUT1G
board (J2000).
The cable at J6020B from the AWG1G board to the CH1 & CH2 OUT1G
board (J3000).
The cable at J6030B from the AWG1G board to the CH1 & CH2 OUT1G
board (J4000).
The cable at J6020C from the AWG1G board to the CH3 & CH4 OUT1G
board (J1000).
The cable at J6030C from the AWG1G board to the CH3 & CH4 OUT1G
board (J2000).
The cable at J6020D from the AWG1G board to the CH3 & CH4 OUT1G
board (J3000).
The cable at J6030D from the AWG1G board to the CH3 & CH4 OUT1G
board (J4000).
The cable at J7800I from the AWG1G board to the Channel 1 Mkr 1
connector.
The cable at J7810I from the AWG1G board to the Channel 1 Mkr 2
connector.
The cable at J7820I from the AWG1G board to the Channel 2 Mkr 1
connector.
The cable at J7830I from the AWG1G board to the Channel 2 Mkr 2
connector.
The cable at J7800J from the AWG1G board to the Channel 3 Mkr 1
connector.
The cable at J7810J from the AWG1G board to the Channel 3 Mkr 2
connector.
The cable at J7820J from the AWG1G board to the Channel 4 Mkr 1
connector.
The cable at J7830J from the AWG1G board to the Channel 4 Mkr 2
connector.
The cable at J1430 from the AWG1G board to the Trigger Input connector.
The cable at J1440 from the AWG1G board to the Event Input connector.
