Troubleshooting

Table 4-8: Diagnostics error

Error code Error log message
AWG register readback
120000000 HwDiagAwgRegister AwgController
address_0x21 register diag. Fail expected
data=xxxx actual data=xxxx
120000001 HwDiagAwgRegister AwgController
address_0x23 register diag. Fail expected
data=xxxx actual data=xxxx
120000002 HwDiagAwgRegister AwgController
address_0x30 register diag. Fail expected
data=xxxx actual data=xxxx
120000003 HwDiagAwgRegister AwgController
address_0x40 register diag. Fail expected
data=xxxx actual data=xxxx
120000004 HwDiagAwgRegister AwgController
address_0x41 register diag. Fail expected
data=xxxx actual data=xxxx
120000005 HwDiagAwgRegister AwgController
address_0x42 register diag. Fail expected
data=xxxx actual data=xxxx
120000006
HwDiagAwgRegister AwgController
address_0x50 register diag. Fail expected
data=xxxx actual data=xxxx
120000007 HwDiagAwgRegister Ch1 MemoryController-N
Communication Fail expected data=xxxx actual
data=xxxx
120000008 HwDiagAwgRegister Ch2 MemoryController-N
Communication Fail expected data=xxxx actual
data=xxxx
120000009 HwDiagAwgRegister Ch1 TEK0015-TNO
address_REG register diag. Fail expected
data=xxxx actual data=xxxx TNO: TEK0015
number REG: Register number
120000010
HwDiagAwgRegister Ch2 TEK0015-TNO
address_REG register diag. Fail expected
data=xxxx actual data=xxxx TNO: TEK0015
number REG: Register number
120000013
HwDiagAwgRegister Ch1 TEK0015-TNO
address_REG register diag. Fail expected
data=xxxx actual data=xxxx TNO: TEK0015
number REG: Register number
4–60
Possible defect
on board Note
AWG1G AWG1G: U1000
AWG1G AWG1G: U1000
AWG1G AWG1G: U1000
AWG1G AWG1G: U1000
AWG1G AWG1G: U1000
AWG1G: U1000
AWG1G
AWG1G AWG1G: U1000
AWG1G AWG1G: U1000, U4000A
AWG1G AWG1G: U1000, U4000B
AWG1G AWG1G: U1000, U4310A, U4420A
AWG1G AWG1G: U1000, U4310B, U4420B
AWG1G AWG1G: U1000, U4310C, U4420C
