Table 4-8: Diagnostics error (cont.)
Error code Error log message
141XP0055 Analog Level Diag CHX 20mhz filter gain
balance failed.
141XP0056
Analog Level Diag CHX 100mhz filter gain
balance failed.
141XP0057 Analog Level Diag CHX amp gain balance failed.
141XP0058 Analog Level Diag CHX A/D converter read
failed.
Output 2 analog level
151XP0031 Analog Level Diag CHX positive (negative) 6db
attenuator failed. Expected 0.5005, actual xxxxx
151XP0032
Analog Level Diag CHX positive (negative) 12db
attenuator failed. Expected 0.2530, actual xxxxx
151XP0033 Analog Level Diag CHX positive (negative) 24db
attenuator failed. Expected 0.0631, actual xxxxx
151XP0034 Analog Level Diag CHX positive (negative)
20mhz filter failed. Expected 0.975, actual xxxxx
151XP0035 Analog Level Diag CHX positive (negative)
100mhz filter failed. Expected 0.995, actual
xxxxx
151XP0036 Analog Level Diag CHX positive (negative) amp
failed. Expected 8.95, actual xxxxx
151XP0037 Analog Level Diag CHX positive (negative)
output offset failed. Expected 2.0V, actual
xxxxxV
151XP0038 Analog Level Diag CHX positive (negative)
output offset failed. Expected 0.0V, actual
xxxxxV
151XP0040 Analog Level Diag CHX positive (negative) D/A
internal offset1 failed. Expected 0.0mV, actual
xxxxxmV
151XP0041 Analog Level Diag CHX positive (negative) D/A
internal offset2 failed. Expected 0.0mV, actual
xxxxxmV
151XP0042 Analog Level Diag CHX positive (negative) read
D/A gain11 failed. Expected 0.300V, actual
xxxxxV
AWG5000B and AWG5000C Series Service Manual
Possible defect
on board Note
OUT1G OUT1G: K1120, K1125, K2120, K2125,
K3120, K3125, K4120, K4125
OUT1G OUT1G: K1120, K1125, K2120, K2125,
K3120, K3125, K4120, K4125
OUT1G OUT1G: U1140, U1145, U1160A/B,
U2140, U2145, U2160A/B, U3140, U3145,
U3160A/B, U4140, U4145, U4160A/B
OUT1G OUT1G: U5010, U5100, U5112, U5114
OUT1G OUT1G: K1100, K2100, K3100, K4100
OUT1G OUT1G: K1105, K2105, K3105, K4105
OUT1G OUT1G: K1110, K2110, K3110, K4110
OUT1G OUT1G: K1120, K1125, K2120, K2125,
K3120, K3125, K4120, K4125
OUT1G OUT1G: K1120, K1125, K2120, K2125,
K3120, K3125, K4120, K4125
OUT1G OUT1G: U1140, U1145, U1160A/B,
U2140, U2145, U2160A/B, U3140, U3145,
U3160A/B, U4140, U4145, U4160A/B
OUT1G OUT1G: U1200, U1220, Q1218, Q1228,
U2200, U2220, Q2218, Q2228, U3200,
U3220, Q3218, Q3228, U4200, U4220,
Q4218, Q4228
OUT1G OUT1G: U1200, U1220, Q1218, Q1228,
U2200, U2220, Q2218, Q2228, U3200,
U3220, Q3218, Q3228, U4200, U4220,
Q4218, Q4228
AWG1G AWG1G: U6000, U6025, U6035 [C-D]
AWG1G AWG1G: U6000, U6025, U6035 [C-D]
AWG1G, AWG1G: U6000, U6015 [C-D],
OUT1G
J6020 [C-D], J6030 [C-D]
OUT1G: J1000, J2000, J3000, J4000
