Diagnostics and troubleshooting
70
12.3

Diagnostic event in the operating tool

If a diagnostic event is present in the device, the status signal appears in the top left status
in the operating tool along with the corresponding symbol for event level in accordance
with NAMUR NE 107:
• Failure (F)
• Function check (C)
• Out of specification (S)
• Maintenance required (M)
A: Via the operating menu
1. Navigate to the Diagnostics menu.
 In the Actual diagnostics parameter, the diagnostic event is shown with event
text.
2. On the right in the display range, hover the cursor over the Actual diagnostics
parameter.
A tool tip with remedial measures for the diagnostic event appears.
B: Via the "Create documentation" function
1.
Select the "Create documentation" function.
2.
Make sure "Data overview" is marked.
Levelflex FMP53 PROFIBUS PA
Endress+Hauser
