Structure and function of the operating menu

8.2.1

Structure of the operating menu

Menu
2)
Commissioning
Setup
Diagnostics
5)
Expert
Contains all the parameters of the device
(including those that are already contained in
one of the other menus). This menu is
organized according to the function blocks of
the device.
The parameters of the Expert menu are
described in:
GP01001F (PROFIBUS PA)
Submenu / Meaning
parameter
1)
Language Defines the operating language of the
local display
Launches the interactive wizard for
guided commissioning.
Additional settings generally do not need
to be made in the other menus when the
wizard is finished.
Parameter 1 Once values have been set for these
... parameters, the measurement should
Parameter N generally be completely configured.
Advanced setup Contains additional submenus and
parameters:
• For more customized configuration of
the measurement (adaptation to
special measuring conditions).
• For converting the measured value
(scaling, linearization).
• For scaling the output signal.
Diagnostic list Contains up to 5 currently active error
messages.
3)
Event logbook Contains the last 20 messages (which are
no longer active).
Device information Contains information for identifying the
device.
Measured values Contains all current measured values.
Data logging Contains the history of the individual
measuring values.
Simulation Is used to simulate measured values or
output values.
Device check Contains all parameters needed to check
the measurement capability of the
device.
4)
Heartbeat Contains all the wizards for the
Heartbeat Verification and Heartbeat
Monitoring application packages.
System Contains all higher-level device
parameters that do not pertain either to
the measurement or to measured value
communication.
Sensor Contains all parameters needed to
configure the measurement.
Output Contains all parameters needed to
configure the switch output (PFS).
Operation methods
41
