Operating menu
Confirm distance
Navigation
Description
Mapping end point
Navigation
Description
Record map
Navigation
Description
Distance
Navigation
Description
108
16.3.1

"Mapping" wizard

The Mapping wizard is only available when operating via the local display. When
operating via an operating tool, all parameters concerning the mapping are located
directly in the Setup menu (→  101).
In the Mapping wizard two parameters are displayed simultaneously on the display
module at any one time. The upper parameter can be edited, whereas the lower
parameter is displayed for reference purposes only.
Navigation 
 Setup → Mapping → Confirm distance
→  106
 Setup → Mapping → Map. end point
→  107
 Setup → Mapping → Record map
→  107
 Setup → Mapping → Distance
→  104
Setup → Mapping
