Level Unit; Blocking Distance - Endress+Hauser Levelflex FMP53 Operating Instructions Manual

Operating menu

Level unit

Navigation
Description
Selection
Additional information

Blocking distance

Navigation
Description
User entry
Factory setting
Additional information
116
 Setup → Advanced setup → Level → Level unit
Select level unit.
SI units
• %
• m
• mm
The level unit may differ from the distance unit defined in the Distance unit parameter
(→  101):
• The unit defined in the Distance unit parameter is used for the basic calibration (Empty
calibration (→  103) and Full calibration (→  103)).
• The unit defined in the Level unit parameter is used to display the (unlinearized) level.
 Setup → Advanced setup → Level → Blocking dist.
Specify upper blocking distance UB.
0 to 200 m
For rod and rope probes up to 8 m (26 ft): 200 mm (8 in)
Signals in the upper blocking distance are only evaluated if they have been outside the
blocking distance when the device was switched on and move into the blocking distance
due to a level change during operation. Signals which are already in the blocking distance
when the device is switched on, are ignored.
This behavior is only valid if the following two conditions are met:
• Expert → Sensor → Echo tracking → Evaluation mode = Short time history or Long
time history)
• Expert → Sensor → Gas phase compensation → GPC mode= On, Without correction
or External correction
If one of these conditions is not met, signals in the blocking distance will always be
ignored.
A different behavior for signals in the blocking distance can be defined in the
Blocking distance evaluation mode parameter.
If required, a different behavior for signals in the blocking distance can be defined by
the Endress+Hauser service.
US units
• ft
• in
Levelflex FMP53 PROFIBUS PA
Endress+Hauser


