Closing the cover of the electronics compartment
1.
1. Screw down the cover of the electronics compartment.
2. Turn the securing clamp 90 ° in the clockwise direction and, using an Allen key
(3 mm), tighten the screw of the securing clamp on the electronics compartment
cover with 2.5 Nm.
6.3

Post-installation check

 Is the device undamaged (visual inspection)?
 Does the device comply with the measuring point specifications?
• Process temperature
• Process pressure
• Ambient temperature range
• Measuring range
 Are the measuring point identification and labeling correct (visual inspection)?
 Is the device adequately protected against precipitation and direct sunlight?
Is the device adequately protected against impact?
Are all mounting and safety screws securely tightened?
 Is the device properly secured?
3 mm
2. 2.5 Nm
Mounting
A0021451
