Integration into a PROFIBUS network
56
9.2

Setting the device address

 17 Address switch in the connection compartment
9.2.1

Hardware addressing

1. Set switch 8 to the "OFF" position.
2. Using switches 1 to 7, set the address as indicated in the table below.
The change of address takes effect after 10 seconds. The device is restarted.
Switch 1
Value in 1
"ON"
position
Value in 0
"OFF"
position
ON
1 2
2 + 8 = 10
 18 Example of hardware addressing; switch 8 is set to the "OFF" position; switches 1 to 7 define the address.
9.2.2

Software addressing

1. Set switch 8 to "ON".
2. The device restarts automatically and reports the current address (factory setting:
126).
3. Configuring the address via the operating menu: Setup → Device address
ON
1
2
 19 Example of software addressing; switch 8 is set to the "ON" position; the address is defined in the operating
menu (Setup → Device address).
2 3 4
2 4 8
0 0 0
DIP
3 4 5 6 7 8
DIP
3 5 6 8
4 7
Levelflex FMP53 PROFIBUS PA
5 6
16 32 64
0 0
Endress+Hauser
A0015686
7
0
A0015902
A0015903
