Operating menu
Selection
Additional information

Assign limit

Navigation
Prerequisite
Selection

Assign diagnostic behavior

Navigation
Prerequisite
Description
Selection
* Visibility depends on order options or device settings
142
• Off
• Digital output AD 1
• Digital output AD 2
• Digital output 1
• Digital output 2
• Digital output 3
• Digital output 4
The Digital output AD 1 and Digital output AD 2 options refer to the Advanced
Diagnostic Blocks. A switch signal generated in these blocks can be transmitted via the
switch output.
 Setup → Advanced setup → Switch output → Assign limit
Switch output function (→  141) = Limit
• Off
• Level linearized
• Distance
*
• Interface linearized
*
• Interface distance
*
• Thickness upper layer
• Terminal voltage
• Electronic temperature
*
• Measured capacitance
• Relative echo amplitude
• Relative interface amplitude
• Absolute echo amplitude
• Absolute interface amplitude
 Setup → Advanced setup → Switch output → Assign diag. beh
Switch output function (→  141) = Diagnostic behavior
Select diagnostic behavior for switch output.
• Alarm
• Alarm or warning
• Warning
*
*
Levelflex FMP55 PROFIBUS PA
