Commissioning via operating menu
60
11.4

Recording the reference envelope curve

After the measurement has been configured, it is recommended to record the current
envelope curve as a reference envelope curve. This can then be used later for diagnostic
purposes. The Save reference curve parameter is used to record the envelope curve.
Path in the menu
Expert → Diagnostics → Envelope diagnostics → Save reference curve
Meaning of the options
• No
No action
• Yes
The current envelope curve is saved as a reference curve.
This submenu is only visible for the "Service" user role in devices supplied with
software version 01.00.zz.
The reference envelope curve can only be displayed in the envelope curve diagram of
FieldCare after it has been loaded from the device into FieldCare. The "Load Reference
Curve" function in FieldCare is used for this.
 23 "Load Reference Curve" function
Levelflex FMP55 PROFIBUS PA
Endress+Hauser
