Levelflex FMP55 PROFIBUS PA

Channel

Navigation
Description
Selection
Additional information

PV filter time

Navigation
Description
User entry
* Visibility depends on order options or device settings
Endress+Hauser
16.3.2

"Analog input 1 to 6" submenu

There is an Analog input submenu for each AI block of the device. The AI block is
used to configure the measured value transmission to the bus.
Only the most basic properties of the AI blocks can be configured in this submenu. For
a detailed configuration of the AI blocks refer to Expert → Analog inputs → Analog
input 1 to 6.
Navigation 
 Expert → Analog inputs → Analog input 1 to 6 → Channel
Standard parameter CHANNEL of the Analog Input Block according to the PROFIBUS
Profile.
• Level linearized
• Distance
*
• Interface linearized
*
• Interface distance
*
• Thickness upper layer
• Terminal voltage
• Electronic temperature
• Measured capacitance
• Absolute echo amplitude
• Relative echo amplitude
• Absolute interface amplitude
• Relative interface amplitude
• Absolute EOP amplitude
• Noise of signal
• EOP shift
*
• Calculated DC value
• Sensor debug
• Analog output adv. diagnostics 1
• Analog output adv. diagnostics 2
Allocates a measured value to the AI block.
 Expert → Analog inputs → Analog input 1 to 6 → PV filter time
Standard parameter PV_FTIME of the Analog Input Block according to the PROFIBUS
profile.
Positive floating-point number
Expert → Analog inputs → Analog input 1 to 6
*
*
*
Operating menu


111
