Levelflex FMP55 PROFIBUS PA

Distance unit

Navigation
Description
Selection

Tank type

Navigation
Prerequisite
Description
Selection
Factory setting
Additional information

Tube diameter

Navigation
Prerequisite
Description
User entry
Endress+Hauser
 Setup → Distance unit
Length unit for distance calculation.
SI units
• mm
• m
 Setup → Tank type
Medium type = Liquid
Select tank type.
• Metallic
• Bypass / pipe
• Non metallic
• Mounted outside
• Coaxial
Depending on the probe
• Depending on the probe some of the options mentioned above may not be available or
there may be additional options.
• For coax probes and probes with metallic center washer Tank type parameter
corresponds to the type of probe and cannot be changed.
 Setup → Tube diameter
• Tank type (→  101) = Bypass / pipe
• The probe is coated.
Specify diameter of bypass or stilling well.
0 to 9.999 m
US units
• ft
• in
Operating menu



101
