Operating menu

Confirm distance

Navigation
Description

Mapping end point

Navigation
Description

Record map

Navigation
Description

Distance

Navigation
Description
110
16.3.1

"Mapping" wizard

The Mapping wizard is only available when operating via the local display. When
operating via an operating tool, all parameters concerning the mapping are located
directly in the Setup menu (→  100).
In the Mapping wizard two parameters are displayed simultaneously on the display
module at any one time. The upper parameter can be edited, whereas the lower
parameter is displayed for reference purposes only.
Navigation
Setup → Mapping → Confirm distance
→  107
Setup → Mapping → Map. end point
→  109
Setup → Mapping → Record map
→  109
Setup → Mapping → Distance
→  104
Setup → Mapping
Levelflex FMP55 PROFIBUS PA
Endress+Hauser
