Levelflex FMP55 PROFIBUS PA
Additional information

Out status

Navigation
Description
User interface
Additional information

Out status HEX

Navigation
Description
User entry
Additional information
Endress+Hauser
• For Mode block actual = Man:
Enter the output value of the Analog Input Block.
• Else:
Displays the output value of the Analog Input Block.
 Diagnostics → Analog inputs → Analog input 1 to 6 → Out status
Element Status of the standard parameter OUT in the Analog Input Block accordintg to
the PROFIBUS Profile.
• Good
• Uncertain
• Bad
Only the two quality bits are evaluated in this parameter.
 Diagnostics → Analog inputs → Analog input 1 to 6 → Out status HEX
Element Status of the standard parameter OUT in the Analog Input Block according to the
PROFIBUS Profile.
0 to 255
The complete status byte is displayed in the form of a two-digit hexadecimal number in
this parameter.
Operating menu
169
