Side Panels; Underside Panel - Teldat 4Ge Installation Manual

3 Components and Power Supply
Rear panel
Fig. 2:
The following table provides information on each connector as well as a description:
Rear panel elements table
Item
A
B
C

3.1.3 Side Panels

Two WWAN antennas are located on the side panels, one on either side.
Right hand side panel
Fig. 3:

3.1.4 Underside Panel

The following elements can be found on the underside panel:
6
Description
RESET. Reset button. For further information on how the reset button operates,
please see RESET Button
ETHERNET. Gigabit Ethernet.
Power source connection (PSU).
Left hand side panel
and Fig. 4:
on page 13 in this chapter.
Teldat S.A.
Teldat 4Ge Router
