Technical Information

Appendix A Technical Information

A.1 Troubleshooting
The following table can help you solve problems when installing the device. If you cannot solve the problem, contact
your dealer for more information.
Symptom
None of the LEDs light up on
the router.
You have forgotten the router's
access password.
The LAN Switch LED never
lights up in green.
The Eth WAN LED never lights
up in green.
The USB LED never lights up in
green.
A.2 Updating the software
The Teldat iM8-Cx router can be updated to new versions. Please contact your dealer for information on new re-
leases.
A Teldat router can be updated in several ways. For further information, please see manual: "Teldat- Dm 748-I Soft-
ware Updating" .
The software required to update Teldat routers is supplied in a format known as distribution. This consists of a
single file containing all the files needed to update your device, as well as in-depth information on the contents of the
files.
A.3 Connecting to the device
A.3.1 Connecting using the local console (Aux connector)
The Teldat iM8-Cx router has a RJ45 female connector on the front panel, known as "Aux", that provides access to
the device local console.
Aux Connector
Fig. 12:
To configure this, you must connect the "Aux" port to an asynchronous terminal (or to a PC with terminal emulation).
Note
The configuration for the terminal must be:
14
Solution
Check the power supply to the router (power source, ON/OFF switch, main power
outlet).
Ignore the configuration through the RST button (as explained in the relevant sec-
tion).
Check the Ethernet cable and the connection to the network.
Check that the appropriate license is available for use.
Check the Ethernet cable and the connection to the network.
Check that the router supports the device inserted in the USB connector.
Check the appropriate license is available for use.
