3.2 Assembly Group Seat

3.2.5 Adjusting the stabilizing rod

(3a+b) When widening the seat, the stabilizing
rod must be adjusted to the new measure-
ments. There are two different kinds of stabiliz-
ing rods:
• 3a single piece (for extendable push
handles),
• 3b three piece (for standard push
handles).
• After widening, the single piece stabiliz-
ing rod must be place in the appropri-
ate hole (A) and screwed on tightly.
• As for the three piece stabilizing rod,
the middle piece must be displaced in
to the appropriate hole (B) and after-
ward screwed together tightly.
2022-12-19
(3a)
(3b)
Service Record Vector & Vector BSA
(A)
(B)
