3.3 Assembly Group Leg Supports

3.3.1 General Information Leg supports

Model 1: inner attachment (1a) or outer (1b)
(1a)
Model 4: inner attachment (3a) or outer (3b)
(3a)
Model 6 Vector: inner attachment
(5)
The leg support is optimally adjusted when, with the leg standing at right angles to the footpla-
te, the entire thigh rests evenly on the seat cushion / seat molding up to about the width of the
finger in front of the hollow of the knee.
Depending on the seat depth, the legrest is pre-set with a knee angle of 90 ° or 105 °.
18 of 40
(1b)
(3b)
Service Record Vector & Vector BSA
Model 2: inner attachment (2a) or outer (2b)
(2a)
Model 5: outer attachment
(4a)
Model 6 Vector BSA: outer attachment
(5)
