strings are case sensitive.
The user number designated for a v3-user. The NetGuardian supports up to four
ID
v3-User profiles.
The name of the user for which an SNMPv3 management operation is performed.
Username
Access Mode This identifies the security modes available when SNMPv3 is utilized. The modes are
as follows:
· No-Auth, No-Priv- This access mode does not require authentication and does not
require encryption. This mode is the least secure and is comparable to v1 and v2c.
· Auth-MD5,No-Priv- Provides authentication based on the MD5 algorithm and does
not require encryption.
· Auth-SHA,No-Priv- Provides authentication based on the SHA algorithm and does
not require encryption.
· Priv Auth-MD5- Provides authentication based on the MD5 algorithm and provides
DES 56-bit encryption based on the CBC-DES standard.
· Priv Auth-SHA- Provides authentication based on the SHA algorithm and provides
DES 56-bit encryption based on the CBC-DES standard.
This field contains the password used with either MD5 or SHA authentication
Auth Pass
algorithms.
Priv Pass
This field contains the password used with p
Defines the SNMP trap manager's IP address. Set to 255.255.255.255 if not using.
IPA
The SNMP port is the UDP port set by the SNMP manager to receive traps, usually
Port
set to 162.
Select between v1-Trap, v2c-Trap, v2c-Inform, or v3-Trap.
Format
Number of times the NetGuardian will resend SNMP v2c-Informs
Retry
Time interval in seconds between attempts to resend SNMP v2c-Informs.
Seconds
Association to the v3-User Table is made to specify the username, security mode, and
v3-Users
passwords that should be used for sending a v3-Trap.
If you are using SNMPv3, any changes to the Engine ID or passwords will require a reboot.
At bootup,you may experience a slight delay while the authorization and privatization keys update.
v3-Users
Global Trap Managers
Fields in the Edit > SNMP settings
rivatization encryption.
9
