6: Basic Troubleshooting and Chassis Service
Unpacking
Control Panel
Drive Bay Installation/Removal
Accessing the Drive Bays
44
•
When handling chips or modules, avoid touching their pins.
•
Put the serverboard, add-on cards and peripherals back into their anti-static bags when not in
use.
•
For grounding purposes, make sure your computer chassis provides excellent conductivity
between the power supply, the case, the mounting fasteners and the serverboard.
Replacement components are usually shipped in anti-static packaging to avoid static damage.
When unpacking an upgrade or replacement component, make sure the person handling it is static
protected.
The control panel (located on the front of the chassis) must be connected to the JF1 connector on
the serverboard to provide you with system status indications. A ribbon cable has bundled these
wires together to simplify the connection. Connect the cable from JF1 on the serverboard to the
Control Panel PCB (printed circuit board). Make sure the red wire plugs into pin 1 on both
connectors. Pull all excess cabling out of the airflow path. The LEDs inform you of system status.
See Chapter 3 for details on the LEDs and the control panel buttons.
This section describes hard drive installation and removal.
Drives: You do not need to access the inside of the chassis or remove power to replace or swap a
RAIDed hard disk drive. Data may be lost or corrupted if you "hot swap" a JBOD disk drive. Shut
down system power before removing or replacing a JBOD disk. Removing either a RAID or
JBOD drive without replacing it may cause system errors. Proceed to the next section for further
hard drive instructions.
