Server Chassis Features

System Power

Serial ATA Subsystems

Front Control Panel

Serverboard and PCIe Subsystem

007-6465-001
The following subsections provide a general outline of the main features of the ISS C1104-GP6
chassis.
The SGI ISS C1104-GP6 1U chassis features a redundant power supply composed of two separate
power modules. This power redundancy feature allows you to replace a failed power supply
without shutting down the system. Note that each power supply provides up to 500 Watts of power
to the system.
The server chassis supports up to four 3.5-in SATA drives. Chassis drives are SATA 3.0
6-Gb/second slots. RAID 1 drives are hot-swappable units and are connected to a backplane that
provides power and control. Note that the operating system you have installed must support RAID
to enable the hot-swap capability of RAID drives. Certain RAID levels may require use of
optional hardware or software to support RAIDed hard disk drives in the server.
The control panel on the ISS C1104-GP6 provides you with chassis monitoring and control. LEDs
that indicate system power, HDD activity, network activity and a chassis overheat/fan-fail/ UID
LED. A main power button and a system reset button are also included.
The ISS C1104-GP6 chassis is an ATX form factor chassis designed to be used in a 1U rackmount
configuration. The serverboard's I/O backplane supports two standard size (full-height x16) PCIe
cards and one half-height (x8) PCIe card which can offer optional computing solutions. A 15-pin
VGA port, a serial (COM) port, two USB 3.0 and two USB 2.0 ports, two Gigabit LAN ports and
a dedicated RJ-45 IPMI LAN port are also supported.
