NIC2

HDD

Info LED

26
Figure 3-7 LAN1 Network Activity NIC1 LED Example
When flashing, the NIC2 LED indicates network activity on the LAN2 port (see
Figure 3-8 LAN2 Network Activity NIC2 LED Example
The HDD LED indicates hard drive activity when flashing (see
Figure 3-9 Hard Drive Activity LED Example
The info LED can indicate multiple states that may require attention. An example LED
designation is shown in Figure
• If the LED shows a solid red it indicates an overheat condition - check the environmental
temperature and look for "cable congestion" or other obstructions that might impede air flow
to the server.
1
2
3-10. This LED has several states:
Figure 3-8).
Figure 3-9).
