5: System and Serverboard Information
CPUs
Memory
PCIe Expansion and PCIe Cards
System Health Monitoring
36
•
The Intel PCH C612 chipset is used on the system serverboard.
•
Eight DIMM slots supporting 2400/2133/1866/1600 MHz registered DDR4 ECC SDRAM.
Note: DIMM speeds available may depend on the type of processors installed. Check with
your authorized sales/service representative for installation of approved DIMM types.
•
Use of two separate riser cards supports three optional PCIe cards at the rear of the system as
follows:
–
One rear-accessible PCIe Gen 3.0 x8 low-profile card (in x16 slot)
–
Two rear-accessible PCIe Gen 3.0 x16 full-height cards
Note:
PCIe types
supported are limited, check with your sales or support representative for
more information.
•
Onboard voltage monitors
•
Fan status monitor with firmware/software on/off and speed control
•
Watch Dog
•
Environmental temperature monitoring via BIOS
•
Power-up mode control for recovery from AC power loss
•
System resource alert (via included utility program)
•
Auto-switching voltage regulator for each CPU core
•
CPU thermal trip support
•
I2C temperature sensing logic
•
Chassis intrusion detection
007-6465-001
