the cables and make sure all fans are present and operating normally. You should also check to
make sure that the chassis covers are installed. This LED will remain flashing or on as long as the
indicated condition exists.
Figure 3-4 Overheat/Fan Fail LED
When flashing, the NIC1 LED indicates network activity on the LAN1 port (see
Figure 3-5 LAN1 Network Activity NIC1 LED
When flashing, the NIC2 LED indicates network activity on the LAN2 port (see
Figure 3-6
LAN2 Network Activity NIC2 LED
The HDD LED indicates hard drive drive activity when flashing (see
1
2
Control Panel LEDs
Figure 3-5).
Figure 3-6).
Figure 3-7).
