3: System Interface

NIC1

NIC2

HDD

22
When flashing, the NIC1 LED indicates network activity on the LAN1 port (see
Figure 3-6
LAN1 Network Activity NIC1 LED
When flashing, the NIC2 LED indicates network activity on the LAN2 port (see
Figure 3-7
LAN2 Network Activity NIC2 LED
The HDD LED indicates hard drive activity when flashing (see
Figure 3-8 Hard Drive Activity LED
1
2
Figure 3-6).
Figure 3-7).
Figure 3-8).
007-5841-001
