Statistics panel contains:
three statistics values
two Count down information values
Meaning of the values is:
Good - number of operations which where successfully completed
Fail - number of operations which where not successfully completed
Total - number of all operations
Ctdn - informs about Count down activity (En (enabled) or Disabled)
R emains - informs about remaining number of device operations to do
Notes: When project file is loaded all statistics values are set to zero and Ctdn is set to
Disabled.
For multiprogramming Pg4uwMC software, the statistics information is also saved to
Job Summary report.
Options / View Log...
Command displays content of current Log window. At top right corner is the button [x],
which is used for closing the Log window and displaying of main screen.
Options / Protected mode...
Protected mode is special mode of the program. When the program is in Protected
mode, there are disabled certain program operations and commands. Protected mode
is used to prevent the operator from modifying program or device
in significance. Protected mode is suitable especially for the programming of a large
amount of the same type of devices.
Protected mode can be activated by this menu option or by loading project file that has
activated Protected mode.
Protected mode settings are saved to configuration .ini file of Pg4uwMC. D
s tart of program Pg4uwMC the Protected mode settings from .ini file are used.
When Protected mode menu command is used, password dialog will appear. User
has to enter password twice to confi
p assword confirmation program switches to Protected mode.
Good, Fail, Total.
Ctdn status and value.
rm the password is correct. After successful
