9. Save project: click on
of project etc.
You can make a project on other ELNEC programmers (BeeProg+...) too.
For more details see Help for PG4UW (single site driver) and "User manual for all
ELNEC programmers".
The latest manual may be found at

Production mode

There are two modes:
Mode A: without external display, keyboard and mouse connected to BeeHive8S.
Programming control is only via build in display with touch screen.
Mode B: with external display, keyboard and mouse
Programming control is via Pg4uwMC displayed on external displ
Warning: External display, keyboard and mouse not needed in this mode.
This part of the software is focused on the easy monitoring of high-volume production
operations via graphical control unit with touch screen.
The user can control the following basic operations:
• load project file
• connect/disconnect programmer sites
• select desired device master operation (blank check, verify, program, erase)
• start/stop device operation on connected programmer sites
• set some advanced options to customize available settings, for example Automatic
YES! Function
• create Job report
• create Problem report
• copy project file(s) from external drive (for example from network drive, USB key
etc.) to the standalone's local [Projects] folder
• see the progress of device operation, including statistics information, serialization...
Step by step instruction
Starting Stand-Alone multiprogramming system
1. Check if the power switch placed at back side of programmer, near power supply
connector is on position '0'.
Plug the power cord in to the programmer power supply connector and turn on
2.
the programmer by the power switch placed at back side of programmer. If
programmer not starts (cooling fans not start) please, push the "Soft power
ON/OFF" button on back side, bellow banana jacks.
icon and select destination folder, write a description
www.elnec.com part download.
20
ELNEC s.r.o.
connected to B eeHive8S.
ay.
